Inductive sensor NBB1,5-8GM40-Z0 PEPPERL FUCHS

Description

General specifications
Switching function Normally open (NO)
Output type Two-wire
Rated operating distance sn 1.5 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 1.21 mm
Actual operating distance sr 1.35 ... 1.65 mm typ.
Reduction factor rAl 0.22
Reduction factor rCu 0.16
Reduction factor r304 0.64
Output type 2-wire
Nominal ratings
Operating voltage UB 5 ... 60 V
