KFD2-VR4-EX1.26 Pepperl+Fuchs Voltage Repeater

Description

General specifications
Signal type		Analog input
Functional safety related parameters
Safety Integrity Level (SIL)		SIL 2
Supply
Connection		Power Rail or terminals 11+, 12-
Rated voltage		19 ... 30 V DC
Ripple		within the supply tolerance
Power dissipation		≤ 1.2 W
Power consumption		≤ 1.6 W
Input
Connection side		field side
Connection		terminals 4 (common), 1, 3 and 5 (supply -), 2 and 6 (signal -)
Input resistance		10 kΩ terminals 4 (common), 6-/2-
Output rated operating current		terminals 4 (common), 5-: > 10 mA at -21 V or > 20 mA at -18 V terminals 4 (common), 1-: 5.3 mA ±0.4 mA at -10 V terminals 4 (common), 3-: 3.6 mA ±0.7 mA at -10 V, 20 °C (68 °F)
Transmission range		-20 ... 0 V
Output
Connection side		control side
Connection		terminals 7-, 8+
Voltage		-20 ... 0 V
Load		≥ 9 kΩ (3-wire sensor), ≥ 2 kΩ (2-wire sensor)
Output resistance		24 Ω typ., 27 Ω maximum Since this is much less than the end-to-end resistance of a zener barrier, it may be necessary to specify a monitor intended for use without a barrier. Please follow the advice of the monitor manufacturer.
Transfer characteristics
Cut-off frequency		10 kHz (-0,1 dB) 20 kHz (-1 dB)
Deviation		DC transfer error (with 10 kΩ load) < 10mV
	After calibration	additional error with AC superimposed is ±5 mV at 20 °C (68 °F) at any point within the span, provided that the alternating component of the input voltage is not excessive, e. g. - square waves (0 ... 20 kHz): 5 V_pp - sine waves (0 ... 20 kHz): the full span of 20 V_pp (= 100 g peak acceleration at 100 mV/g) is acceptable.
	Influence of ambient temperature	(< 100 ppm of span)/K at any point within the span
Time delay relative to input		7.1 ±0.3 µs
Ripple		in 200 kHz bandwidth < 20 mV_rms in 20 kHz bandwidth < 3 mV_rms
Galvanic isolation
Output/power supply		functional insulation, rated insulation voltage 50 V AC
Indicators/settings
Display elements		LED
Labeling		space for labeling at the front
Directive conformity
Electromagnetic compatibility
	Directive 2014/30/EU	EN 61326-1:2013 (industrial locations)
Conformity
Electromagnetic compatibility		NE 21:2017 EN IEC 61326-3-2:2018
Degree of protection		IEC 60529
Protection against electrical shock		UL 61010-1
Ambient conditions
Ambient temperature		-20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection		IP20
Connection		screw terminals
Mass		approx. 125 g
Dimensions		20 x 119 x 115 mm (0.8 x 4.7 x 4.5 inch) (W x H x D) , housing type B2
Mounting		on 35 mm DIN mounting rail acc. to EN 60715:2001
Data for application in connection with hazardous areas
EU-type examination certificate		BAS 02 ATEX 7206
	Marking	II (1)G [Ex ia Ga] IIC , II (1)D [Ex ia Da] IIIC
	Input	Ex ia Ga, Ex ia Da
	Voltage	-26.4 V
	Current	90 mA
	Power	570 mW
Supply
	Maximum safe voltage	253 V (Attention! The rated voltage can be lower.)
Output
	Maximum safe voltage	253 V (Attention! The rated voltage is lower.)
EU-type examination certificate		DMT 01 ATEX E 133
	Marking	I (M1) [Ex ia] I
Certificate		TÜV 99 ATEX 1499 X
	Marking	II 3G Ex nA II T4
Galvanic isolation
	Input/Output	safe galvanic isolation acc. to IEC 60079-11, voltage peak value 375 V
	Input/power supply	safe galvanic isolation acc. to IEC 60079-11, voltage peak value 375 V
Directive conformity
	Directive 2014/34/EU	EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010 , EN 50303:2000
International approvals
UL approval
	Control drawing	116-0316 (cULus)
IECEx approval
	IECEx certificate	IECEx BAS 05.0078 IECEx BAS 10.0085X
	IECEx marking	[Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I Ex nA II T4 Gc
General information
Supplementary information		Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
