Description
Technical Data
General specifications
Switching function Normally open (NO)
Output type PNP
Rated operating distance sn 8 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 6.48 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
Reduction factor r304 0.7
Reduction factor rBrass 0.45
Output type 3-wire
Nominal ratings
Operating voltage UB 5 ... 60 V
Switching frequency f 0 ... 1500 Hz
Hysteresis H typ. 5 %
Reverse polarity protection reverse polarity protected
General specifications
Switching function Normally open (NO)
Output type PNP
Rated operating distance sn 8 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 6.48 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
Reduction factor r304 0.7
Reduction factor rBrass 0.45
Output type 3-wire
Nominal ratings
Operating voltage UB 5 ... 60 V
Switching frequency f 0 ... 1500 Hz
Hysteresis H typ. 5 %
Reverse polarity protection reverse polarity protected
