Description
Technical Data
General specifications
Switching function Normally open (NO)
Output type NPN
Rated operating distance sn 8 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 6.48 mm
Actuating element mild steel, e. g. 1.0037, SR235JR (formerly St37-2)
24 mm x 24 mm x 1 mm
Reduction factor rAl 0.38
Reduction factor rCu 0.35
Reduction factor r304 0.74
Reduction factor rBrass 0.47
Output type 3-wire
Nominal ratings
Operating voltage UB 5 ... 36 V
Switching frequency f 0 ... 1350 Hz
General specifications
Switching function Normally open (NO)
Output type NPN
Rated operating distance sn 8 mm
Installation flush
Output polarity DC
Assured operating distance sa 0 ... 6.48 mm
Actuating element mild steel, e. g. 1.0037, SR235JR (formerly St37-2)
24 mm x 24 mm x 1 mm
Reduction factor rAl 0.38
Reduction factor rCu 0.35
Reduction factor r304 0.74
Reduction factor rBrass 0.47
Output type 3-wire
Nominal ratings
Operating voltage UB 5 ... 36 V
Switching frequency f 0 ... 1350 Hz
